The HM406T2 is a 40 kVA fully automatic, six-channel heat treatment unit for preheating and annealing metal workpieces. They are ensuring the clients receive innovative equipment, designed with industry requirements such as ease-of-use and a long product lifetime in mind!
The setting, controlling, monitoring, and documentation of heat treatment parameters are carried out by Heatmasters’ computerized state-of-the-art control system. All channels can be independently programmed. 12 heating elements can be connected, two per channel.
Heat treatment process
HM406T2 will carry out the programmed heat treatment process according to the given parameters. The process can be monitored from the controller, or managed using a laptop (even remotely with a GSM data line). This means heating can be started at any time, even remotely.
Thanks to its signal light system, the operating status of the heat treatment unit is always known
The controller registers the achieved heat treatment results in its memory, which enables easy preparation of heat treatment documents. A separate temperature recorder is not needed. Thanks to its signal light system, the operating status of the heat treatment unit is always known and possible disturbances in the electrical network or heating resistors are noticed right away by the operator. The stainless steel body gives the unit a sleek look and a long lifetime!
Minimizing maintenance work
The unit uses thyristors in power output control, minimizing maintenance work and resulting equipment downtime. It is also relatively portable, weighing only half of the weight of traditional heat treatment units, and being small enough to move around by hand, even through doorways, etc. Designed for on-site heating works, this unit is popular among the customers and their own wizards – working in facilities such as nuclear power plants or chemical plants, where equipment mobility is an important factor.
The product range covers the market’s most advanced heat treatment units for pre-heating and PWHT of metal objects. This includes semi- and fully automatic units available in 3 or 6 channel variants with heating power up to 50kVA. They also offer portable inverter-based units.
