Nicknamed the gateway to Southern California, the city of Ontario, as well as neighboring city Montclair, is home to the third largest elementary school district in California, the Ontario-Montclair School District (OMSD).

Founded in 1884, the district also incorporates portions of the city of Upland, and unincorporated areas of San Bernardino County, comprising 24,000 students in 26 elementary schools and six middle schools.

Ontario-Montclair School District

Ontario-Montclair School District’s overall mission is simple yet speaks volumes to its dedication to all students, to do whatever it takes to guarantee its commitment in providing the highest quality education for all students. To meet this mission head-on, OMSD contracted with TMAD Taylor Gaines, a professional engineering consulting and services firm.

Ontario Montclair School District was interested in reducing their overall energy costs by 20%"

Ontario Montclair School District was interested in reducing their overall energy costs by 20%, they along with other school districts throughout California were mandated to reduce their overall energy costs,” said John Simmons, RCDD, LEED AP, and Project Manager for TMAD Taylor Gaines.

He adds, “We initially ran some numbers based upon information we found on Bard HVAC’s website, and through consultation with Geary Pacific Supply, Bard’s largest West Coast distributor.

Geary Pacific, distributor of new HVAC units

Based upon the scope of the projects in consideration, the money available to fund them and the overall cost of the units in consideration, as well as overall potential energy savings, TMAD Taylor Gaines recommended that OMSD select Geary Pacific as the distributor of the new HVAC units.

We considered other companies as part of our overall recommendation but in all honesty we were impressed by a couple of things. First, Bard Manufacturing had a wealth of product and technical information about their products on their website, including case studies of other customer successes. That in combination with Geary Pacific’s previous experience working successfully with the School District made our recommendation a simple one,” added John Simmons.

Bard wall-mounted HVAC units deployed

Our District was already familiar with Bard because we had success using some of their other wall mounted units on several of our modular school buildings,” said Craig Misso, Director of Facility Planning & Operation at Ontario Montclair School District, adding “Our goal was to not only upgrade our facilities and make them more energy efficient, but also work to reduce some of the HVAC noise inside the classroom, as well as save on the purchase, operation and maintenance of all of the units at our schools.

TMAD Taylor Gaines and Geary Pacific’s approach was to do the retrofit in several phases. The pilot project encompassed one site, Sultana Elementary School, which included 24 re-locatable buildings, made up of both newer and some older construction.

Bard WG*S Step Capacity Series units with CO2 sensors

TMAD Taylor Gaines and Geary Pacific started doing groups of schools, encompassing 14 different building sites

Sultana was a great school for the pilot because there were a lot of little issues to contend with and work through,” stated Simmons, adding “The Bard WG*S Step Capacity Series units with Energy Recovery Ventilators and CO2 sensors worked great and we were initially very surprised at how quiet they actually operated.

After that, TMAD Taylor Gaines and Geary Pacific started doing groups of schools, encompassing 14 different building sites. Group one included 6 schools and approximately 83 units while Group 2 included 8 schools and 101 units.

It was during the second group of installations that TMAD Taylor Gaines realized that putting in units that required the installation of underground gas piping was not the best solution for all classrooms.

Bard’s Quiet Climate 2 units

That’s when Geary Pacific recommended utilizing Bard’s Quiet Climate 2 units with Energy Recovery Ventilators and CO2 sensors in about 1/3 of the overall installation. “Bard’s Quiet Climate 2 units are some of the most energy-efficient HVAC units on the market today,” said Maury Tiernan of Geary Pacific, adding “Plus the operational sound level is extremely low and is greatly appreciated by the students and teachers.”

John Simmons said, “We were really pleased at how easily these units were able to be retrofitted into the re-locatable classrooms. There are almost no changes and smooth sailing in almost all cases.

Quiet, efficient operation

The dramatic reduction in operating noise levels was an added improvement and benefit for which Craig Misso was particularly proud. “At Sultana, we invited some of the teachers and our principal over to see the new classrooms. Our principal asked, ‘Why aren’t the new HVAC units running’? I had to laugh, because I knew they were on. They were just so quiet nobody could tell that they were working. That moment sold every teacher on the Bard units,” added Craig Misso of Ontario Montclair School District.

From the very beginning, Geary Pacific became our partner in the success of the project,” stated Simmons, adding “Always available to answer questions on-site and knowledgeable about all aspects of the product and installation I can honestly say they can’t do anything wrong by me. Geary Pacific and the engineers at Bard Manufacturing came through in every way possible and more.

Wall-mounted heating and cooling equipment expert

Bard’s HVAC products offer a combination of quiet operation, and energy efficiency

Over thirty years ago, Bard Manufacturing began solving the comfort needs of schools across the country by providing wall-mounted heating and cooling equipment. Bard’s HVAC products offer a combination of quiet operation, and energy efficiency, with unsurpassed quality and dependability that make them the #1 choice for schools.

With three, state-of-the-art manufacturing facilities and a global distribution network, Bard’s commitment to quality and product innovation begins with its commitment to research and development. With features like self-diagnostics and self-programming energy monitors, Bard delivers products that provide tangible solutions for any school.

Energy and cost savings

The Bard units reduced ambient classroom noise levels by over 75% and further gave us a 50% savings in energy,” said Misso, adding “This savings allowed us to also install software on our computers that automatically turns off the lights and the AC, when the classrooms are unoccupied, which further increased our savings. Our hope is to have the funds necessary to install all 280 Bard units as specified by TMAD Taylor Gaines.

Misso concluded, “Geary Pacific has been extremely professional and service oriented throughout the project. Because of our School Board’s commitment to energy conservation, our District will receive a dual reward, recognized energy savings and efficiency with an enhanced classroom environment for our students and teachers. We couldn’t ask for anything more.
